WEG TPW Series HMIs

Intuitive Visualization for WEG Drives & PLCs

TPW04/07 touchscreen HMIs deliver powerful visualization in a compact footprint. With Ethernet, serial, and USB connectivity, TPW panels connect directly to WEG PLCs and CFW drives, offering modern graphics, alarming, and remote access for machine builders and facilities.

Request HMI Quote Schedule Demo Search TPW HMIs

Hardware Highlights

4.3" and 7" high-brightness TFT displays with 65k colors
Resistive touch with glove-friendly operation
Compact 45 mm panel depth for shallow enclosures
Front bezel rated up to IP65/NEMA 4X

Connectivity

Ethernet, RS-232/485, and USB host/device ports
Native drivers for WEG PLCs, CFW drives, and third-party controllers
Support for Modbus TCP/RTU, EtherNet/IP, and OPC UA (select models)
Integrated data logging and recipe management via SD card

Visualization Tools

WEG HMI Editor software with symbol libraries and trend objects
Advanced alarm handling with email/text notifications
Multi-language support and user security levels
Remote viewer for maintenance access over VPN or cloud gateway

Applications

Packaged pumping systems with WEG PLC and VFD control
OEM machine control panels and operator stations
Building automation dashboards
Energy monitoring and drive diagnostics

Create Connected Operator Experiences

Unified Programming

Use WEG HMI Editor to synchronize tag databases with WLP PLC projects and CFW drive parameters for seamless commissioning.

Smart Diagnostics

Trend motor current, energy consumption, and alarm history to support predictive maintenance programs.

Remote Visualization

Built-in VNC server enables secure remote monitoring from tablets, laptops, or service centers.

Edge Connectivity

Optional MQTT/OPC UA gateways connect TPW panels to enterprise dashboards and cloud analytics.

HMI Resources

HMI Editor Software

Request the latest programming software and driver packages for TPW series panels.

Request Software

Communication Driver List

Review supported PLCs, drives, and protocols along with configuration tips.

Request Driver List

Sample Projects

Starter screens and templates for pump control, HVAC dashboards, and alarm summaries.

Request Samples
